- Laptop controller using Windows based operating system.
- Unlimited programming capability.
- Multi-color graphing of sample, chamber, and program temperature.
- Temperature set points by sample or chamber.
- Programs and freeze data saved to hard drive or disc.
- Password protected software.
- Searchable database for freeze run history.
- Freeze run graphs and data available via any standard USB printer.
- 30 data fields available for each freeze run.
- Continuous digital and graph display for time and temperature during operation.
- Manual overrides for all operating functions.
- Temperature range +50°C to -180°C.
- Freezing rates of 0.01° to 99.9° per minute.
- Program temperature hold of 1 second to 99 hours.
- Six pre-set easy to run freeze programs.
Chamber Specifications
Power requirements:
120 volt, 50/60 Hz, 10 amp, or
230 volt, 50/60 Hz, 10 amp
Outside dimensions:
Depth: 25 1/2” (648 mm) (including vent)
Height: 29 1/4” (743 mm) (including computer)
Width: 19 1/16” (484 mm) (including hose connection)
Inside dimensions:
Depth: 9 9/16” (243 mm)
Height: 13 3/4” (349 mm)
Width: 14” (356 mm)
28 Liters
Power requirements:
120 volt, 50/60 Hz, 10 amp, or
230 volt, 50/60 Hz, 10 amp
Outside dimensions:
Depth: 25 1/2” (648 mm) (including vent)
Height: 29 1/4” (743 mm) (including computer)
Width: 19 1/16” (484 mm) (including hose connection)
Inside dimensions:
Depth: 9 9/16” (243 mm)
Height: 13 3/4” (349 mm)
Width: 14” (356 mm)
28 Liters
